The Faraday disk from 1831.
A is the horseshoe-shaped inducing magnet.
B is the binding screw for current entering or exiting the axis of the disk.
B' is the binding screw for current entering or exiting the circumference of the disk.
D is the induced copper disk.
m is the sliding spring contact.
A is the horseshoe-shaped inducing magnet.
B is the binding screw for current entering or exiting the axis of the disk.
B' is the binding screw for current entering or exiting the circumference of the disk.
D is the induced copper disk.
m is the sliding spring contact.
